JBL

BassPro SL

Details
Item# BASSPRO SL
Variations
  • Select Color
Product Actions
Add to cart options

Additional Information
The BassPro SL powered woofer fits under the front seat of many vehicles, and supplements a car audio system’s full-range speakers with powerful bass.
At a Glance:
  • Proprietary, shallow-profile woofer
  • Efficient Class D amplifier
  • Intelligent electronic design
  • System Control
  • Line- and high-level inputs
  • Wired, remote level control capability
What's in the Box:
  • 1 powered woofer enclosure
  • 4 mounting screws
  • Owner’s manual
The BassPro SL powered woofer fits under the front seat of many vehicles, and adds powerful bass to any car audio system. An electronic crossover control and flexible EQ adjustments let you tune the BassPro SL to your system, your car’s acoustic environment and your listening preferences. The energy-efficient digital amplifier provides a powerful engine to drive the subwoofer while staying cool even when driven hard. The BassPro SL delivers great bass output without taking up a lot of space.
Product Features:
  • Proprietary, shallow-profile woofer
    The 8" (200mm) woofer in the BassPro SL is designed specifically to provide low distortion, great bass performance contained in our proprietary ABS enclosure, which has a remarkably compact footprint.
  • Efficient Class D amplifier
    The amp that powers the BassPro SL produces minimal heat, and it doesn’t require a lot of current from the car’s electrical system.
  • Intelligent electronic design
    The BassPro SL employs custom circuitry to protect and provide optimum performance at varying output levels without impacting performance or clarity.
  • System Control
    An electronic crossover control provides variable adjustment from 50Hz- 120Hz allowing you to dial-in BassPro SL to best integrate with the rest of your car audio system.
  • Line- and high-level inputs
    For added installation flexibility, the BassPro SL features both line- and high-level inputs allowing you to connect to both factory installed and aftermarket systems. If you use the high-level inputs to connect the BassPro SL to the head unit, an input load switch lets you switch from “Low” to “High” to achieve optimum results.
  • Wired, remote level control capability
    The BassPro SL is compatible with the RBC Remote Bass Controller (sold separately), which enables you to control the level remotely.
Manuals & Downloads:
General Specifications:
Amplifier Power
125W RMS
Fuse
20A
Maximum Current Draw
12A
Quiescent Current Draw
less than 800mA
Input Sensitivity
0.2V – 2V Line-Level Input; 2V – 20V High-Level Input
Audio Specifications:
Frequency Response
35Hz – 120Hz
Crossover Frequency
50Hz – 120Hz
Crossover Slope
12dB/octave
Bass Boost
0dB to +9dB @ 70Hz
Dimensions:
Width
9-7/8"; (250mm)
Length
13-9/16"; (344mm)
Woofer Specifications:
Woofer
8"; (200mm)
