JBL 104-BT (Pair)
€ 199,00
JBL 104-BT (Pair) Coaxial driver design - Image

Coaxial driver design

With 4.5-inch (118 mm) LF driver and .75-inch (19 mm) soft-dome HF driver

JBL 104-BT (Pair) Integrated 60-watt Class D power amplifier - Image

Integrated 60-watt Class D power amplifier

Distributes 30 watts to each speaker

JBL 104-BT (Pair) Acoustically optimized - Image

Acoustically optimized

For desktop placement


JBL 104-BT (Pair) Three sets of inputs and built-in Bluetooth - Image

Three sets of inputs and built-in Bluetooth

Allow connection with professional equipment, personal music players and consumer products

JBL 104-BT (Pair) Smart features - Image

Smart features

Include front-panel volume control, input selection and headphone jack with automatic speaker mute

Specs & Downloads

Item# 104SET-BT-EK-LS


Legendary Sound - No Strings Attached

JBL 104-BT compact reference monitors with Bluetooth, the newest models in the 1 Series line, draw from seven decades of JBL Professional engineering to deliver the truest, most accurate sound in their class. They’re perfect for recording musicians, producers, podcasters and vloggers, as well as professional audio engineers seeking an accurate portable reference with Bluetooth streaming. JBL 104-BT Reference Monitors combine a powerful coaxial 4.5-inch (118 mm) low-frequency driver and .75-inch (19 mm) soft-dome tweeter, potent integrated 60-watt amplification and an innovative acoustic design to reproduce honest sound with exceptional imaging and crisp detail. Bluetooth streaming lets you check mixes over Bluetooth to make sure they sound great in every listening scenario. Both the black 104-BT and white 104-BTW versions are sleek, elegant designs and compact form factors, making stunning statements in any studio while conserving valuable work space. Creative professionals, music lovers and anyone who wants the flexibility to stream both wired and wireless sound into high-quality studio monitors can count on JBL 104-BT to provide an accurate, reliable sonic reference and a truly enjoyable listening experience.

Device Compatibility


General Specifications

Bluetooth Version
Low Frequency Transducer
4.5 in (118 mm)
High Frequency Transducer
0.75 in (19 mm), soft dome
1725 Hz, 1st order
Power Amp
60 W (30 W each speaker), Class D
87 dB SPL @ 1 m with -10 dBV Aux In (Volume = Max)
Maximum Continuous SPL
89 dB
System Peak SPL
102 dB (pink noise, 12 dB crest factor)
Maximum SPL, Momentary Peak
104 dB
Maximum Peak Input Level (-10 dBV / +4 dBu):
+6 dBV / +20.3 dBu
Frequency Range (-3 dB SPL)
88 Hz – 20 kHz
Frequency Range (-10 dB SPL)
60 Hz – 20 kHz
System Rated Impedance
8 Ω
Minimum Impedance
7.8 Ω @ 260 Hz
Cabinet Tuning Frequency
72 Hz
System Distortion Criteria
<10% THD at maximum output with full compressor / limiter engagement
Electrical Distortion Criteria
<0.2%THD @ 1 kHz, 2.83 VRMS output; <1% THD @ 1 kHz, full rated output
Signal to Noise Ratio
75 dBA (A-Weighted), 70 dBr (unweighted), relative to 2.83 VRMS output on HF
Coverage (Horizontal x Vertical)
120º x 60º
Acoustic Test Specification
ATS# 1000340443


9.72 in (247 mm)
6.02 in (153 mm)
4.88 in (124 mm)
Net Weight
Primary Monitor = 4.54 lb (2.06 kg); Secondary Monitor = 3.81 lb (1.73 kg)


Enclosure Type
Enclosure Material
ABS with metal grille
Enclosure Finish
Matte black acrylic paint (104-BT) ; Matte white acrylic paint (104-BTW)

Audio Output

System Output Type
1/8" stereo headphone with auto speaker mute

Audio Input

System Input Type
Bluetooth, 1/8" Aux, RCA, 1/4" TRS balanced
Input Selection Options
Bluetooth, Aux, RCA, TRS, All

Powering Interface

System Power Handling
30 W x 2 @ 100 hours, IEC/SMS
System Polarity
AC Input Voltage
100 – 240 VAC (± 10%), 50/60 Hz
Current Draw
85 watts
Electrical Current Draw (W) Idle 100 / 240 VAC
3.52 / 3.70
Electrical Current Draw (W) Max Power 100 / 240 VAC
80 / 80
Electrical Current Draw (W) Low Power Standby Mode 100 / 240 VAC
0.34 / 0.46

What's in The Box?

  • 1 x 104-BT Master Monitor
  • 1 x 104-BT Extension Monitor
  • 1 x Extension monitor speaker wire (2-conductor, 2 meters)
  • 1 x 3.5 mm to RCA audio cable
  • 1 x Regional power cable
  • 1 x Quick setup guide
